Diamond Dressing Tool Johnsontools-1

Inquiry

Product details of the diamond dressing tool

Product Introduction

johnsontools's collection is made up of diamond dressing tool materials. The product is superior in performance, durability, and usability. 苏州乔盛进出口有限公司's customer service is highly recommended by clients.

PRODUCT ADVANTAGES

Our customer service team is a dedicated, hard-working group specially selected for their enthusiasm and commitment to providing excellent customer service. They offer advice, answer any queries.

Core Bit Type:

Premium grade for fast drilling and extended product life.

Connection Type:

Available with M14 and 5/8”-11 shaft connections.

Customization:

Production strictly follows customer requirements, and the size can be customized.

Usage:

Suitable for core drilling machines and hand drills.

PRODUCT parameter

Dry core bits for granite
Diameter	Segment Dimension		Teeth No.	Vacuum brazed Protect Teeth
mm	Height	Thickness	Teeth No.	Vacuum brazed Protect Teeth
6	10	2	Crown	——
8	10	2	Crown	——
10	10	2	Crown	——
12	10	2.5	Crown	——
14	10	2.5	Crown	——
16	10	2.5	Crown	——
18	10	2.5	Crown	——
20	10	2.5	Crown	4(O)2(I)
25	10	2.5	Crown	4(O)2(I)
32	10	3	4	4(O)2(I)
35	10	3	4	4(O)2(I)
38	10	3	4	4(O)2(I)
50	10	3	5	4(O)2(I)
60	10	3	6	4(O)2(I)
70	10	3	7	4(O)2(I)
80	10	3	8	4(O)2(I)
90	10	3	9	4(O)2(I)
100	10	3.5	9	4(O)2(I)

product usage

6mm,8mm,10mm-100mm Diamond Dry Core Drills Bits with Brazing Rods for Granite,Quartz, and Marble

Core Drilling for Thinner Stone Applications:

Core drilling thinner applications of stone, including granite, marble, sandstone, limestone, and so on.
Premium grade core bits that deliver fast drilling speed and extend product life.
Use application with core drilling machines and hand drills.
Production strictly according to customer requirements.
Size could be customized.
