Vacuum Brazed Special Shape Diamond Profile Wheels
Applications:
Vacuum brazed diamond profile wheels are mainly used for profiling the edge or curve line for various granite, marble, engineered stone on stone profile machine.Special diamond profiling wheel can be made according to requirements of different customers. Wet use or dry use are both ok for diamond profile wheels during edging and curving.
Advantage:
1. Special diamond brazing technology makes diamond is firmly brazed onto the center.
2. Applied to various stone.
3. High grinding effect and long working life.
4. They are the best tools to replace electroplated profile wheel.
5.They are excellent for grinding without losing their shape
6. Our quality have been accepted by international market.
Shapes: All kind of shapes stone can be designed, such as, Eased, Half Bullnose, Bevel, Ogee, Normandy Bead, Cove, Stairtread, Full bullnose, Dupont, etc.
Outer diameter: 140mm, 200mm, 300mm, 350mm, other diameter can be done based on your request.
Height: 10mm, 15mm, 20mm, 30mm, 50mm or as client's special request
Center hole: 30mm or 50mm.
Diamond Grit: Coarse, Medium, Fine.
Main market: Middle Asia, America, Europe, Oceania
Spec.:
Diameter | Hole x Thickness | Diamond Grit |
140mm | 30 or 50mm x 10 to 50 mm | coarse, medium, fine |
200mm | 30 or 50mm x 10 to 50 mm | coarse, medium, fine |
300mm | 30 or 50mm x 10 to 50 mm | coarse, medium, fine |
350mm | 30 or 50mm x 10 to 50 mm | coarse, medium, fine |
Tag: Diamond milling bits Automatic cutting machine Diamond profile wheels Diamond grinding cup wheels
