Johnson Tools Hole Saw Arbor Center Bit Pilot Drill for Diamond Core Masonry Drill Bit

Specifications:

Upgrade your drilling rig to a dust-free system with the Johnson Tools Vacuum Dust Collector Adapter. Designed for professional electricians and HVAC installers, this adapter connects between your handheld drill and the diamond core bit, extracting hazardous silica dust directly from the source before it enters the air.

Why Use Our Dust Collector Adapter?

Health & Safety Compliance: Essential for indoor work. It captures up to 95% of airborne dust, keeping the job site clean and protecting you from inhaling concrete dust.
Standard M22-M16 Fit: Features an M22 Female thread (to connect to your drill motor) and an M16 Male thread (to connect to standard diamond core bits).
360° Swivel Hose Port: The outer housing rotates independently from the drill shaft, ensuring your vacuum hose stays untangled and positioned conveniently while you drill.
Precision Centering: Includes a slot for a Pilot Drill (Center Bit), allowing you to start your hole accurately without the bit wandering on the wall.

Product Name: Vacuum Dust Collector

Thread Specification: M22 Female - M16 Male

Cover Diameter: Less than 82mm

Application: Designed for use with Dry Core Bit

Inquiry

Write a Review

Get In Touch With Us

PRODUCT ADVANTAGES

Our customer service team is a dedicated, hard-working group specially selected for their enthusiasm and commitment to providing excellent customer service. They offer advice, answer any queries.

Dry Operation Support:

No water is required during use, eliminating the need for water supply systems in the drilling and coring process, and simplifying the operation process.

Dust Reduction & Safety Enhancement:

Equipped with a dust extraction valve and collector port, it can significantly reduce airborne dust generated during dry diamond core drilling, effectively keeping the workspace clean and improving operational safety.

Flexible Hose Setup:

Features a rotatable outer housing, which allows flexible adjustment of the hose direction and position, adapting to different rig layouts and operation angles.

High Drilling Accuracy:

Integrated with a pilot bit, it enables precise centering before drilling, effectively improving the accuracy of drilling on hard materials like concrete or masonry, reducing deviation.

product usage

- Suitable for the drilling and coring process (no water needed, realizing dry operation).

- Recommended for use with fixed rigs or hand-held rigs, compatible with different operation scenarios.

- Specifically matched with dry diamond core drilling, ideal for working on hard materials such as concrete and masonry.

Consistent Customer Praise

Our products consistently receive high praise from satisfied customers, reflecting their excellence and reliability.

Guaranteed Satisfaction！！

We are confident that you will experience the same level of satisfaction as our esteemed customers.

Your contentment is our top priority.

Q1: Will this fit my core drill?

A: This adapter fits drills with a standard M22 Male spindle. Please check your drill's manual. It converts the connection to M16 Male for the core bit.

Q2: Do I need a special vacuum cleaner?

A: We recommend a Class M or Class H industrial vacuum cleaner for concrete dust. The adapter port is designed to fit standard vacuum hoses.

Q3: How does the pilot bit work?

A: The pilot bit (usually a taper shank) fits into the center of the adapter. You use it to start the hole. Once the core bit has cut a groove (about 5-10mm deep), you simply remove the pilot bit and continue drilling with just the dust collector attached.

Q4: Can I use this for wet drilling?

A: This specific model is designed for Dry Drilling to extract dust. For wet drilling, you would typically use a water swivel adapter instead.
